Whole HouseWater Refining System
Soft, clean, truly refined water. Combines water softening and carbon filtration in one dual-tank system with a single control valve.
Same benefit as separate systems -- at a fraction of the cost.
Hydrotech HTO Up Flow Series
Rid your water of hardness minerals (calcium and magnesium) plus filter out bad tastes and odor caused by chlorine, chloramines or organic matter. The unique two tank system keeps the two media beds separate, allowing for more carbon contact which greatly improves removal. You get the same benefit as a separate water softener and whole-house carbon filter for a much lower price as the single control valve operates both systems.
IAPMO R&T Certified against NSF/ANSI 44 and CSA B483.1. Certified by IAPMO R&T to NSF/ANSI 42 for chlorine reduction.
How the HTO Combo SystemRefines Your Water
Two separate media tanks operated by a single control valve deliver complete water treatment
Catalytic Carbon Tank
Removes 97% of chlorine, chloramines, and organic compounds. Over 1.1 million gallon capacity. Separate tank allows for easy, cost-effective carbon replacement.
Softening Resin Tank
Aquafine 8% cation exchange resin removes hardness minerals (calcium and magnesium). Up Flow Regeneration saves salt and preserves unused resin.
Brine Tank
High-density polyethylene tank with lifetime warranty. Brine safety valve and plastic salt grid prevent bridging and overflow. Up to 420 lbs salt storage.
Because carbon typically needs replacement before softening resin, the separate tank design allows for easy, cost-effective maintenance
System Specifications
Available in five sizes to match your home's water usage and hardness levels
Model Comparison
| Specification | HTO100 | HTO150 | HTO200 | HTO250 | HTO300 |
|---|---|---|---|---|---|
| Hardness Removal (Grains) | 25,000 | 37,500 | 50,000 | 67,500 | 75,000 |
| Carbon Quantity | 1.0 ft3 | 1.5 ft3 | 2.0 ft3 | 2.5 ft3 | 3.0 ft3 |
| Resin Quantity | 1.0 ft3 | 1.5 ft3 | 2.0 ft3 | 2.5 ft3 | 3.0 ft3 |
| Tank Size | 9x48 | 10x54 | 12x52 | 13x54 | 14x65 |
| Salt Per Regen | 6.0 lbs | 9.0 lbs | 12.0 lbs | 15.0 lbs | 18.0 lbs |
| Flow Rate @ 15 psi | 7.2 GPM | 7.4 GPM | 9.0 GPM | 9.2 GPM | 9.2 GPM |
| Flow Rate @ 25 psi | 10.0 GPM | 10.1 GPM | 11.9 GPM | 12.1 GPM | 12.1 GPM |
Available with 89 Series (1" elbows, 4-line touchpad) or 785 Series (3/4" elbows, 2-line display) control valves
Why Choose the HTO Combo System?
One system, complete water treatment -- soft, clean, truly refined water
Great Tasting Water
Catalytic carbon removes chlorine, chloramines, and organic compounds. No more chemical taste or odor from every tap in your home.
Soft Skin & Silky Hair
Hard water leaves skin dry and hair brittle. The softening resin removes calcium and magnesium for noticeably softer water.
Protect Your Plumbing
Scale buildup damages water heaters, dishwashers, and plumbing. Softened water extends the life of your appliances and fixtures.
Cost-Effective Solution
Get the same benefit as separate water softener and whole-house carbon filter at a much lower cost with a single control valve.
What You'll Experience
Industry-Leading Warranties
Built to last with comprehensive warranty coverage on every component
Control Valve
NSF Certified valve
Pressure Tanks
NSF Certified fiberglass
Brine Tank
High-density polyethylene
Certifications
ANSI 42 & ANSI 44
Combo System vs. Separate Units
See why the HTO combo system is the smart choice for complete water treatment
HTO Combo System
Separate Systems
Ready for Truly Refined Water?
Get a free water test and we'll recommend the right HTO system size for your home. One system for soft, clean, great-tasting water from every tap.
